DTT VOIP-GSM 8M72S: SMS-Email 72 SIm card gateway

• Scanning of BCCH channel by cyclic or static
• IMEI changing
• Image moving from point to point (pair of IMEI and SIM card) Available only with external Sim server DTT use and several remote gateways DTT as part of the system

VOIP

• Signaling: SIP – RFC 3261
• support up to 32 sip clients as a sip server
• simultaneously
• Codec’s: G.711A,Mu G723 G.726 G.726 G.729
• Acting as a SIP Server.
• SIP Account management + Authentication


Interfaces

• WAN, LAN
• GSM 8 Channel with 1 External Antenna SMA
• type with 3.6 meter length



File Title	Release Date	File Type	Size (mb)	Action
API for DTT VOIP-GSM ver. 7.2B10	10-15-2014	Software (zip)	8.70 MB	download
API for DTT VOIP-GSM gateways ver. 7.1B48_26	10-15-2014	Software (exe)	9.34 MB	download
API for DTT VOIP-GSM gateways (7.1B48)	10-15-2014	Software (rar)	9.02 MB	download
API for DTT VOIP-GSM gateways (7.1B47_22)	10-15-2014	Software (rar)	8.95 MB	download
SMS VOIP gateway. Installation	11-11-2013	Documentation (pdf)	0.16 MB	download
User manual for DTT VOIP-GSM 8-16-24 gateways	08-01-2018	Documentation (pdf)	1.55 MB	download
User manual for DTT 8-16-24 channel gateways (Version 5.36z)	08-01-2018	Documentation (pdf)	1.44 MB	download
Windows update for DTT VOIP2GSM gateways	06-08-2013	Driver (rar)	2.65 MB	download
IMEI changing in DTT GSM VoIP gateways	06-08-2013	Documentation (pdf)	1.05 MB	download

8 GSM channels gateway with embedded mini sim server for 64 Sim

8 simultaneous calls to Voip, Cellular, with a direct LAN connection to IP-PBX or TCP/IP.
This unit can be intermixed with any 4ch of the cellular options, IE 4 channels GSM / 4 channels CDMA
A SIP Client/Server, that can work stand-alone or in a SIM Server environment
Optional 64 sims (mini sim server)
Timetable for sim swapping and unique human behaviour
Hot swappable sim cards
Solution for: A Corporate heavy duty solution for mass  calling, origination / termination / call centres / operators

SMS-email gateway

A new software innovation for use with all VoIP Channel Banks – allowing SMS capability – both send and receive, as well as optional ‘bulk’ SMS options via Microsoft® Outlook® 2007, Microsoft® Outlook® Express, Thunderbird®, etc.

This feature allows the sending up up to 500 SMSs at the push of one button.* Example: with a 16 channel unit you can send SMSs through all 8 ports simultaneously - a total of 2,000 SMS numbers to 4,000 SMS recipients at the push of a button with a maximum of 8 messages a minute from each port

This software is also able to receive SMS using your regular e-mail application actively from all active ports.

All who require immediate batch notification such as:
Call-centres, Airports, Corporate, Medium & Small Businesses, Schools, Etc
----------------------------------------
*Depending on the operator’s allowance

Following are the advantages of the VoIP GSM / UMTS unit

• Small size unit 1U and below
• Easy to connect
• Flexibility, stand alone gateway or use in sim server system
• Additional 64 sims, (mini sim server) 8ch/64 sim or 16ch/64 sim
• Advanced Human behavior, innovative features such as sim profiling, grouping, test call, test sms and more….
• SIP/H323 interface
• Bulk sms server, till 500 sms calls per port with 1 click, via email server i.e. Microsoft outlook (optional)
• CDR, via Access, Xml, CSV
• Supports most IP-PBX exchanges
• Cost affordable

• NEC
• Alcatel
• Siemens
• Samsung
• ICT
• Davos44.net
• T4xx
• Aastra
• MX one
